| SBC Form Factor |
●CPU: |
| Intel® Atom™ x5-E3930 1.3GHz (up to 1.8 GHz,
dual core, TDP=6.5W) |
| ●Chipset: |
| SoC |
| ●System Memory: |
| 1x 204-pin DDR3L SO-DIMM slot (system max. 8
GB) |
| (DRPC-130-AL-E1/4GB SKU is pre-installed with 4
GB memory) |
| ●Power: |
| Input : 3-pin terminal block: 12 V ~ 24 V DC |
| Consumption: 12V @ 2.88 A (Intel® Atom™
x5-E3930 CPU with 4GB 1600 MHz DDR3L memory) |
| Remote Power: PSON 2-pin terminal block |
| ●Reliability: |
| Operating Shock: Half-sine wave shock 5G, 11ms,
100 shocks per axis, IEC68-2-27 |
| Operating Vibration: MIL-STD-810G 514.6C-1
(SSD) |
| Safety/EMC - CE/FCC |
| Cooling method / System Fan |
Fanless |
| Drive Bays |
1
x 2.5' SATA 6Gb/s HDD/SSD bay |
| Buttons |
1
x Power Button |
| 1 x Reset Button |
| 1 x AT/ATX Switch |
| Indicators |
1
x LED for HDD (Yellow) |
| 1 x LED for Power (Green) |
| I/O Ports |
●USB:4
x USB 3.0 |
| ●Ethernet:2 x RJ-45 (PCIe GbE by Intel® I211
controller) |
| ●COM Port:4 x RS-232/422/485 |
| ●Digital I/O:8-bit digital I/O , 4-bit input /
4-bit |
| ●CAN-Bus:1 x DB-9 w/ 2.5kV Isolation
protection, supporting 2-port CAN-bus |
| ●Display:2 x HDMI 1.4b |
| |
| Operating Temperature |
-20°C
~ 60°C with air flow (SSD) |
| Humidity |
10%
~ 95%, non-condensing |
| Construction |
Extruded
aluminum alloy |
| Dimensions |
58.75
x 130 x 174 |
| Weight |
1.4Kg/2.5Kg |
| Color |
Black |
| Expansion Slots |
PCIe
Mini: |
| 1 x Half-size PCIe Mini slot |
| 1 x Full-size PCIe Mini slot (supports mSATA,
colay with SATA) |
